Stainless Steel Return Pump

The stainless steel return pump is applicable to transport milk and other similar liquid food , absorb the tallest temperature of material as 70-80 °C. This pump is a single suction entire closed type centrifugal pump.

Classification of Stainless Steel Return Pump

live demonstration of pump

1. according to structure, it can be divided into three-foot pump and four-foot pump

2. according to material, there are SUS304 and SUS316L

3. according to motor species, it can be divided into ordinary motor, ABB motor and explosion-proof motor.

Usages of Stainless Steel Return Pump

This stainless steel pump is suitable for urban environmental protection, construction, fire control, chemical, pharmaceutical, printing, dyeing, brewing, electric power, electroplating, papermaking and equipment cooling, etc.

Characteristics of Stainless Steel Return Pump

1, the pump uses rigid structure and excessive thick wall design. All the parts such as pump body, pump cover and impeller that contacts with the material are made by SUS316L or SUS304 stainless steel.

2,Mechanical shaft adopts high quality graphite, carbide silicon or hard alloy steel to produce. Greatly improving the wear resistance and prolong the using life.

3, it is easy to maintenance (open impeller type), between components are strong interchangeability.
